STB-3/8 TC

STB-3/8 TC.37″(9.5mm) Recessed Type W/Terminal Quick-Connect

Contact Size: .37″×.92″(9.5mm×23.3mm)
Standard Magnet Size: .37″×.58″(9.5mm×14.8mm)
Standard Gap: .6″(15mm)
Colors: White, Brown
STB-3/8 TC: Terminal Connect, No Leads.

  • PDF Document
  • C UL US Listed
  • CE
  • RoHS

Specifications

Scroll or swipe left to right on the table below for more information.
Part NumberGap
Inch (mm)
Loop
Open/Closed
Reed
Form
Max. Contact
Rating (W)
Max. Initial Contact
Resistance (mΩ)
Max. Switching
Voltage (V)
Max. Switching
Current (A)
STB-3/8TC.6″(15)CLOSEDNormally
Open
10100AC110/DC1000.5
STB-3/8TC WG1″(25)CLOSEDNormally
Open
10100AC110/DC1000.5
STB-3/8TC DM.5″(12.5)CLOSEDNormally
Open
10100AC110/DC1000.5
STB-3/8TC FLAT.5″(12.5)CLOSEDNormally
Open
10100AC110/DC1000.5
STB-3/8B TC.5″(12.5)OPENNormally
Closed
10100AC110/DC1000.5

OPERATING TEMPERATURE:-40°C to +60°C


Outline Dimensions Unit: inch(mm)

STB-3/8 TC

STB-3/8 TC WG

STB-3/8 TC DM

STB-3/8 TC FLAT

PDF Document Installation Instructions


PDF Document
