FM-45

FM-451.10″L×.49″W×.3″H Side Lead Surface Mount Type (with Super Stick adhesive tape)

Contact Size: 1.10″L×.49″W×.26″H (28mm×12.5mm×6.5mm)
Standard Magnet Size: 1.10″L×.49″W×.26″H (28mm×12.5mm×6.5mm)
Standard Gap: 1″(25.4mm)
Colors: White, Black, Brown, Gray
18″(457mm) 26 AWG Leads Standard
Longer leads available.

  • PDF Document
  • RoHS

Specifications

Scroll or swipe left to right on the table below for more information.
Part NumberGap
Inch (mm)
Loop
Open/Closed
Reed
Form
Max. Contact
Rating (W)
Max. Initial Contact
Resistance (mΩ)
Max. Switching
Voltage (V)
Max. Switching
Current (A)
FM-451″(25.4)CLOSEDNormally
Open
10100AC110/DC1000.5
FM-46B.5″(12.7)OPENNormally
Closed
3100AC30/DC300.2
FM-47C.5″(12.7)SPDTSPDT3100AC30/DC300.2

OPERATING TEMPERATURE:-40°C to +60°C


Outline Dimensions Unit: inch(mm)

FM-45/FM-46B

FM-45 Outline Dimensions

FM-47C

FM-47C Outline Dimensions

FM-47C Wiring Diagram

FM-47C Wiring Diagram

PDF Document Installation Instructions


PDF Document
